DN1600 Cement Lined ISO 2531 BS En 545 En598 Ductile Cast Iron Sewer Drain Pipe & Fittings Factory

DN1600 Cement Lined ISO 2531 BS En 545 En598 Ductile Cast Iron Sewer Drain Pipe & Fittings Factory

DN1600 Cement Lined ISO 2531 BS EN 545 EN598 Ductile Cast Iron Sewer Drain Pipe & fittings factory DETAILED INFORMATION:
Basic Info.
Certification ISO2531, EN545, EN598, ISO4179, ISO8179
Shape Round
Customized Non-Customized
Gasket Material EPDM
Yieid Strength Above 300MPa
Application Water Supply
Density Above 7g/cm3
Certificate Wras, ISO2531
Size DN80-2600
Delivery Time 15-20 Days
Cement Lined 3mm-6mm
Tensile Strength Above 420MPa
Zinc Coat Above 130G/M2
Length 5.7m/6m
Paint Black Bitumen Paint/Epoxy Paint
Item Name ISO2531 En545 Ductile Iron Pipes for Water Supply
Transport Package Wooden Pallets, Steel Bands
Specification DN80-DN2000
Trademark DINGGIN
Origin China
HS Code 7303009000
Production Capacity 20000 Tons Per Month
Product Description
DN1600 Cement Lined ISO 2531 BS EN 545 EN598 Ductile Cast Iron Sewer Drain Pipe & fittings factory
DETAILED INFORMATION:
Zinc coated k9 ductile iron pipes for water supply
1). Material: Ductile iron
2). Size: DN80-DN2600
3). Standard: ISO2531/EN545/EN598
4). Length/pc: 5.7m/6m
5). Class: K7/k9/class c
6). Joint type: T-type, flange-type, K-type
7). Paint: Black bitumen/epoxy paint.
8). Zinc coat: Outside sprayed with zinc (in accordance with ISO8179, not less than 130 g/m2)
9). Cement lining: Inside with cement mortar lining as per ISO4179.
10). Tensile strength: Above 420 MPA
11). Yield strength: Above 300 MPA
12). Brinell hardness: Within 230HBW
13). Density: Above 7g/cm3
14). Spheroidizing grade: Grade 1-3
15). Rubber gaskets: SBR/EPDM/neoprene
16). MOQ: 1 Ton
17). Lead time: Below 1000 tons, 2 weeks. Above 1000 tons, depend on your qty.
18). We could also do the test at famous organizations such as SGS, BV, etc.
Centrifugally Ductile Cast Iron Pipes is a kind of pipes made from Spherical graphite cast iron by centrifugal spinning process.
The pipes can convey various kinds of fluid media such as water, oil and gas, which is widely used in pipesline projects for mine, irrigation projects, petroleum.
Ductile iron pipes:T-type Joint Pipes(Push-on)
Internal Coating:1. portland cement mortar lilning
2.sulphate resistant cement mortar lining
3. high-aluminum cement mortar lining
4. epoxy painting
5. black bitumen painting
External Coating:1. Zinc+bitumen painting
2. Zinc-aluminum alloy+liquid epoxy painting

Benefits buy ductile iron pipes from Dinggin:
1. 100% inspection: every pieces of ductile iron pipes must be tested by factory internal or third party inspection institutions to make its quality.
2. Long service life: the pipes could be service over 100years.
3. Quick Quotation and production time: we could send price within 5hrs in working day, and the production time accoring to qty.
4. Full list of standard: our company could supply all the standard of pipes and fittings, such as ISO/EN/AWWA to meet different countries different proejects demand.
5. We could supply different coatings: bituminous coating, epoxy paint, PU, PE coating etc.
Production process:

DN1600 Cement Lined ISO 2531 BS En 545 En598 Ductile Cast Iron Sewer Drain Pipe & Fittings Factory


DN1600 Cement Lined ISO 2531 BS En 545 En598 Ductile Cast Iron Sewer Drain Pipe & Fittings Factory


DN1600 Cement Lined ISO 2531 BS En 545 En598 Ductile Cast Iron Sewer Drain Pipe & Fittings Factory

EN545/ISO2531 DUCTILE IRON PIPE CHEMICAL CONTENT STANDARD
C (%)Si (%)S (%)P (%)Mn (%)Mg (%)Ti (%)Gr (%)
3.5-4.01.8-2.6<0.02≤0.08≤0.4≥0.04<0.1<0.1
EN545/ISO2531 DUCTILE IRON PIPE MECHANICAL TEST STANDARD
BRINELL HARDNESSDENSITYTENSILE STRENGTHELONGATIONSPHEROIDIZING GRADEWATER PRESSUREZINC COAT
≤230HBW≥7g/cm3≥420DN80-DN1000DN1100-DN2600GRADE 1-350KG≥130
G/M2
10%7%
